Send and Receive SMS Messages with Firebase Functions

< Tutorial />

Send and Receive SMS Messages with Firebase Functions

The Firebase platform allows developers to build an application backend rapidly. It's enjoyable to use as well. For this tutorial, I wanted to start using it for some SMS messaging with Vonage. After this walk-through, you will be able to create an SMS message log and a response to the sender using Firebase Cloud Functions and the Real Time Database alongside the Vonage SMS API.

Before You Get Started

You will need a few items to get going - so take a moment and make sure you have both of these ready to go.

  1. Firebase
  2. Vonage

Setting up Firebase

The first step is to set up a Firebase project. The following will walk you through setting up a new project using the Firebase console.

Create the Firebase Project

  1. Go to Firebase console
  2. Click add project

The Create Project link

  1. Add a name and click continue

Naming your project

  1. Leave Google Analytics on and click continue (not required)
  2. Select a Google Analytics account and then click Create Project (if added)

Configuring Google Analytics

  1. Wait a bit for the project to be created - takes less than a minute.

  2. Set the Billing type under ⚙️ -> Usage and Billing -> Details & Settings to Blaze. The Pay-as-you-go plan is required to use a third-party API. For more details regarding billing with Google, go here.

    Dialog to select a Firebase Pricing Plan

  3. Set the Google Cloud Platform (GCP) resource location in ⚙️ -> Project Settings.

    Setting a resource location in the resource location dialog

Install Firebase Tools

Most everything you will need to do with Firebase can be done directly from the command line with the toolset they provide.

  1. Install the Firebase tools with npm.
npm install -g firebase-tools
  1. Log in to Firebase using firebase login. The login process will open your browser for authentication.

Setup Local Environment

Writing Cloud Functions for Firebase requires some initialization work to get started, but it's mostly done for you using Firebase Tools commands.

  1. Create a project folder mkdir vonage-project && cd vonage-project.
  2. Initialize Cloud Functions for Firebase firebase init functions.
     ######## #### ########  ######## ########     ###     ######  ########
     ##        ##  ##     ## ##       ##     ##  ##   ##  ##       ##
     ######    ##  ########  ######   ########  #########  ######  ######
     ##        ##  ##    ##  ##       ##     ## ##     ##       ## ##
     ##       #### ##     ## ######## ########  ##     ##  ######  ########

You're about to initialize a Firebase project in this directory:

 /your_folders/your-project-name


=== Project Setup

First, let's associate this project directory with a Firebase project.
You can create multiple project aliases by running firebase use --add,
but for now, we'll just set up a default project.

? Please select an option: (Use arrow keys)
❯ Use an existing project
 Create a new project
 Add Firebase to an existing Google Cloud Platform project
 Don't set up a default project

Since you already created a project in the dashboard, you can select Use an existing project which will prompt you to choose the desired project. If you haven't done this, use Create a new project and give it a unique name to create one. You would still need to go to the console to update the location and billing, but it is another option to create Firebase projects.

  1. Select the project name you created.
  2. Select JavaScript.
  3. Choose Y for ESLint if you desire (I recommend it).
  4. Install all dependencies now.

These steps will create the folders and files required to build Firebase Functions and installs all dependencies. Once NPM completes, switch to the functions directory and open index.js in your favorite editor to start adding code.

Create Your First Function

The first function you create will act as a webhook to capture and log incoming SMS messages from Vonage.

The index.js file has some example code provided you won't need. Delete everything and start at the top to add the following code:

const functions = require('firebase-functions');
const admin = require('firebase-admin');

// Initialize Firebase app for database access
admin.initializeApp();

Calling admin.initializeApp(); allows the functions to read and write to the Firebase Real-Time database. Next, use the following method to create your function.

// This function will serve as the webhook for incoming SMS messages,
// and will log the message into the Firebase Realtime Database
exports.inboundSMS = functions.https.onRequest(async (req, res) => {
  let params;
  if (Object.keys(req.query).length === 0) {
    params = req.body;
  } else {
    params = req.query;
  }
  await admin.database().ref('/msgq').push(params);
  res.sendStatus(200);
});

The inboundSMS method listens for HTTPS requests - which is precisely what Vonage webhook needs. The Firebase Function will capture the req.body in case it's a POST Method or the req.query in case it's a GET Method. It then send it to the /msgq object in the Real-Time Database as a log.

Now that you have some code written be sure to save your file an deploy the function to Firebase:

firebase deploy --only functions

=== Deploying to 'vonage-project'...

i deploying functions
Running command: npm --prefix "$RESOURCE_DIR" run lint

> functions@ lint /Users/kellyjandrews/Google Drive/Apps/vonage-project/functions
> eslint .

✔ functions: Finished running predeploy script.
i functions: ensuring necessary APIs are enabled...
✔ functions: all necessary APIs are enabled
i functions: preparing functions directory for uploading...
i functions: packaged functions (38.78 KB) for uploading
✔ functions: functions folder uploaded successfully
i functions: creating Node.js 14 function inboundSMS(us-central1)...
✔ functions[inboundSMS(us-central1)]: Successful create operation.
Function URL (inboundSMS): https://us-central1-vonage-project.cloudfunctions.net/inboundSMS

✔ Deploy complete!

Project Console: https://console.firebase.google.com/project/vonage-project/overview

The vital piece from the output is Function URL (inboundSMS). This URL is required to set up the webhook in Vonage, which you will do next.

From the Vonage dashboard settings, make sure you are using the SMS API, choose post and and copy the output Function URL(inbound SMS) from the terminal console and paste it in the webhook on Vonage.

Settings

Grab your phone and send a message to the phone number. Open up the Firebase console and navigate to database page, and you should see something like this:

Making a Vonage database entry in real-time

Now that there is a way to log incoming messages, you can write a function to do something with the incoming message.

Create the Send Function

So far, you have created a Firebase Function linked to a Vonage phone number for capturing inbound SMS messages. Firebase Functions can also react to database updates. Upon a new entry, the code sends an echo of the original text.

Start by adding Vonage to the dependency list - make sure you do this in the functions directory:

npm i @vonage/server-sdk --save

Next add dotenv to the dependency list.

npm i dotenv --save

Create a .env file and add the environment variables in the functions directory:

VONAGE_API_KEY=
VONAGE_API_SECRET=

You can either use dot env or add the following environment variables to the Firebase config:

firebase functions:config:set vonage.api_key="YOUR_KEY" vonage.api_secret="YOUR_SECRET"

Next, open index.js add @vonage/server-sdk to the requirements at the top, and import the environment variables to initialize Vonage:

require('dotenv').config();

const functions = require('firebase-functions');
const admin = require('firebase-admin');
const Vonage = require('@vonage/server-sdk');

admin.initializeApp();

// If you are using .env
const vonage = new Vonage({
  apiKey: process.env.VONAGE_API_KEY,
  apiSecret: process.env.VONAGE_API_SECRET,
});

// If you are using the Firebase Environment Variables
const {
  api_key,
  api_secret
} = functions.config().vonage;

Now you can create the new function for Firebase to send the response:

// This function listens for updates to the Firebase Realtime Database
// and sends a message back to the original sender
exports.sendSMS = functions.database
  .ref('/msgq/{pushId}')
  .onCreate(async (message) => {
    const { msisdn, text, to } = message.val();
    const result = await new Promise((resolve, reject) => {
      vonage.message.sendSms(msisdn, to, `You sent the following text: ${text}`, (err, responseData) => {
        if (err) {
          return reject(new Error(err));
        } else {
          if (responseData.messages[0].status === '0') {
            return resolve(
              `Message sent successfully: ${responseData.messages[0]['message-id']}`
            );
          } else {
            return reject(
              new Error(
                `Message failed with error: ${responseData.messages[0]['error-text']}`
              )
            );
          }
        }
      });
    });
    return message.ref.parent.child('result').set(result);
  });

The new function will watch for new messages added to the /msgq database object. When triggered, the full Vonage object gets passed as message. This object includes msisdn, which is the originating phone number - yours in this case, and the to number, which is the Vonage virtual number you purchased.

With the phone numbers in hand, as well as the text message, you can now do any number of things. You can create a lookup table to respond with specific data based on the keyword, forward to another system, or in our case, send the original message.

Deploy the Firebase Functions again from the command line:

firebase deploy --only functions

Grab your phone, send another message, and then you should get a response back that looks something like You sent the following text: A text message sent using the Vonage SMS API.

Wrap Up

You have now completed all the steps for this tutorial. You can see the full code on Github.

Now that the initial steps to send and receive messages are complete, my next few posts will take this concept and expand it into controlling some of my home automation via text messages. I would love to hear what you plan to do as well so send me a message on Twitter and let me know.
